Interchangeability: ISO 7241-1B
Shut-off system: not present, free flow
Latching system: balls - bearing
Connection: pulling back the sleeve
Disconnection: pulling back the sleeve
Connectability: without pressure
Disconnection under pressure: not allowed
Threads: BSP – NPT
Sizes: 1/8”, 1/4" , 3/8”, 1/2”, 3/4”, 1”, 1.1/4”, 1.1/2”, 2”
Materials: Female in stainless steel AISI 316
Male in stainless steel AISI 316
Surface treatment: electrolytic polishing
Spring in stainless steel AISI 316
Balls in AISI 316
Seals: standard VITON, on request NBR
Antiextrusion rings: PTFE
Working Temperatures: NBR -20°C +100°C
VITON -15°C +180°C
