The accordance with the ISO 7241-B standard of these couplings assures their interchangeability all over the world.
The B series is mainly used in industry: his hardiness makes it suitable for heavy duties in the steel industry and in the oil plant.
Interchangeability: ISO 7241-1B
Shut-off system: poppet valve
Latching system: balls - bearing
Connection: pulling back the sleeve
Disconnection: pulling back the sleeve
Connectability: without pressure
Disconnection under pressure: not allowed
Threads: BSP – NPTF
Sizes: 1/4" , 3/8”, 1/2”, 3/4”, 1”
Materials: Female in carbon steel
Male in high grade carbon steel,
induction hardened
Steel hardened valve
Surface treatment: zinc plating and Cr III passivation
Springs in C72 steel
High resistance balls 100 C6
Seals: standard NBR, on request VITON
Antiextrusion rings: PTFE
Working Temperatures: NBR -20°C +100°C
VITON -15°C +140°C
For temperature exceeding this values, the quick-release couplings will be
supplied with all components in steel.
