42 MPa (420 bar)
Port sizes: 1/2” ÷ 1” 1/2
Flow rates: 10 ÷ 420 l/min
TECHNICAL DATA
Max. working pressure: 42 MPa (420 bar)
Max. testing pressure: 62 MPa (620 bar)
Min. bursting pressure: 126 MPa (1260 bar)
Fatigue test: 0 ÷ 28 MPa (280 bar)
Bypass valve: standard ∆p 600 kPa (6 bar) ± 10%
Reverse fl ow valve: available on request
Filter element collapse pressure:
∆p 2,1 MPa (21 bar) all types
∆p 21 MPa (210 bar) 2T - 2C - 2D - 2V - TD - TV - TT - TS
Working temperature: -25°C ÷ +110°C
MATERIALS
Head: cast iron Bowl: forged steel
Seals: standard NBR
on request FKM
COMPATIBILITY (ISO 2943)
Full with fl uids: HH-HL-HM-HV-HTG
(according to ISO 6743/4).
For fl uids different than the above mentioned,
please contact our Sales Department.
All tests performed according
to the following standards:
ISO 2941: Element collapse resistance test
ISO 2942: Production integrity test
ISO 2943: Fluids compatibility
ISO 3723: End load test method
ISO 3724: Flow fatigue resistance method
ISO 3968: Pressure drop versus fl ow rate
ISO 16889: Multipass test.
For further information contact our
Technical Dept.
